CPSQ5425
Application
Automotive LED lights
24-channel automotive high-side LED driver
If you need datasheets or other detailed development materials, please contact Mr. Xu guidong.xu@convenientpower.com
| Part Number | CPSQ5425 | |
|---|---|---|
| Vin range(V) | 4.5-40 | |
| Topology | Linear Constant Current | |
| Channels | 24 | |
| Analog/PWM Width Modulation | PWM | |
| Operating frequency (Hz） | N/A | |
| Package | HTSSOP-48 | |
24-Channel Precision High-Side Current Output
AEC-Q100 Grade 1 Automotive Certification
Wide Operating Voltage Range from 4.5V to 40V
Channel Current Set by Resistor, Up to 100mA
8-Bit Independent Current PWM Dimming
8-Bit Independent DC Dimming
Comprehensive Protection Features: Undervoltage Protection, Over-Temperature Protection, Phase-Shifted PWM Dimming
UART Interface
Operating Temperature Range: -40°C to +125°C
HTSSOP-48 Package
